Surface Energy budget/Fluxes
Incoming fluxes are in blue, outgoing are in green, turbulent exchanges with
the atmosphere are in purple. Sub-surface heat fluxes are in red.
|
Hydrology
Water sources due to the various components of the precipitation
are in blue, evapotranspiration sources/sinks are in green, and
canopy drip, snowmelt runoff, surface runoff, drainage and soil
water fluxes are in red.
|
Prognostic variables are in
blue.
Rg |
Incoming shortwave radiation (W m-2) |
Rat |
Incoming longwave atmospheric radiation (W m-2) |
alpha Rg |
Outgoing shortwave radiation (W m-2) |
Rl |
Outgoing longwave atmospheric radiation (W m-2) |
H |
Sensible Heat Flux (W m-2) |
LE |
Latent Heat Flux (W m-2) |
G |
Ground Heat Flux (W m-2) |
Ts |
Surface temperature (K) |
T2 |
Deep soil or Restore temperature (K) |
|
Pr |
Total Precipitation (kg m-2 s-1) |
Pn |
Snowfall (liquid equiv.) (kg m-2 s-1) |
Ps |
Precipitation reaching soil (kg m-2 s-1) |
Pv |
Precipitation intercepted by vegetation (kg m-2 s-1) |
Pg |
Infiltration (kg m-2 s-1) |
Qr |
Surface runoff (kg m-2 s-1) |
D1 |
Surface/deep soil soil water diffusion (kg m-2 s-1) |
K2 |
Gravitational drainage (kg m-2 s-1) |
En |
Sublimation (kg m-2 s-1) |
Eg |
Bare-soil evaporation (kg m-2 s-1) |
Er |
Evaporation from interception (kg m-2 s-1) |
Etr |
Transpiration (kg m-2 s-1) |
Wr |
Canopy water store (kg m-2) |
Wn |
Snow pack SWE (Snow Water Equiv.) (kg m-2) |
wg |
Surface soil water reservoir (m3 m-3) |
w2 |
Bulk soil water reservoir (m3 m-3) |
ds |
Surface reservoir soil depth (m) |
d2 |
Total soil depth (m) |
|
